FC590 Fiber Cleaver is a high precision single fiber cleaver. It is a reliable cleaver for fiber optic network and FTTx FTTH applications. It contains 16-position blade and performs 48,000 times single fiber cleaves. Two hexagonal wrenches allow you to adjust the cleaver blade flexibly.
Features:
- Three steps operation, the slider needs to be pulled to cleaving position by hand
- Compact design
- High reliability
- Good cleaving performance
- 48,000 times cleave per blade
- High stability and precision
Applications:
- FTTx construction
- Optical network construction
- LAN, WAN, and Metro networks
- CATV networks
Specifications:
| Fiber Type | single fiber |
| Cladding Diameter | 125um |
| Fiber Diameter | 250um/900um/2mm/3mm/2*3mm flat drop cable |
| Cleave Angle Capability | averagely ≤0.5˚ |
| Cleave Length | 5~20mm |
| Blade Lifetime | 48,000 fiber cleaves (1,000 times*16 positions*3 blade heights) |
| Dimension | 69W*60D*55H (mm) |
| Net Weight | 310g |
| Plastic Box Size | 126W*89D*65H (mm) |
| Gross Weight | 414g |
Standard Accessories:
| Item | Name | Quantity |
| 1 | FC590 Fiber Cleaver with 1pc of Blade | 1pc |
| 2 | Hexagonal Wrenches | 2pcs |
| 3 | User Manual | 1pc |
| 4 | Cleave Angle Test Report | 1pc |
| 5 | Plastic Box | 1pc |
